Solar Panel Recycling

Solar Panel Physical Recycling Process

The physical recycling method separates valuable materials using mechanical crushing and sorting technology.

Step 1: Frame & Junction Box Removal
The aluminum frame and junction box are removed by an automated dismantling machine.

Step 2: Glass Removal
Tempered glass is separated with a removal rate above 98%.

Step 3: Crushing & Sorting
The remaining panel materials are shredded and crushed. Through vibrating screening, airflow separation, and grinding, the system extracts:

• Silicon Powder
• Copper Powder
• Plastic Powder

The recovery rate can reach more than 98% depending on material composition.

Solar Panel Pyrolysis Recycling Process

The pyrolysis process uses high-temperature cracking technology for deeper material separation.

Step 1
Waste panels are loaded into a sealed reactor.

Step 2
The pyrolysis furnace heats for 8–10 hours to crack encapsulated materials.

Step 3
After processing, glass, silicon wafers, and copper wires are separated through screening and airflow classification.

Dust is fully controlled using advanced pulse dust collectors, ensuring compliance with environmental standards.
